The HPP13D is perfect for running any 20 or 30 LPM tool in tunnels or other areas where gasoline fuel or fumes are not allowed. Not CE approved.
If you have any questions let us know
HYCON HPP13D diesel hydraulic power pack for 20 or 30 LPM tools, with Kohler KD15-440 engine, 120 bar working pressure and 11 L oil tank.
Improved product description: The HYCON HPP13D is designed to operate any 20 or 30 LPM hydraulic tool in tunnels and other areas where gasoline fuel or fumes are not allowed. Its modern single-cylinder diesel engine combines low fuel consumption with enough power to run breakers, rock drills, core drills, cut-off saws and submersible pumps.
The strong HYCON steel frame protects vital components while providing easy access for servicing. The HPP13D delivers an oil flow of 20-30 LPM at a working pressure of 120 bar, with a maximum pressure of 150 bar.
It uses a 10 hp Kohler KD15-440 diesel engine and offers both recoil and electric starting.
| Specification | Value |
|---|---|
| Model | HPP13D |
| Tool compatibility | 20 or 30 LPM hydraulic tools |
| Tools mentioned | Breaker, rock drill, core drill, cut-off saw, submersible pump |
| Oil flow | 20-30 LPM |
| Working pressure | 120 bar |
| Max. pressure | 150 bar |
| Hydraulic oil tank | 11 L |
| Engine | Kohler KD15-440 |
| Engine power | 10 hp |
| Engine type | Single-cylinder diesel |
| Fuel | Diesel |
| Fuel tank capacity | 4.7 L |
| Starter | Recoil/Electric |
| Frame | HYCON steel frame |
| CE approval | Not CE approved |
